Waveshare 7.5inch E-Paper Hat Display Module, 800x480 Resolution, Supports Black/White 2 Colors, Compatible with Jetson Nano/Raspberry Pi 4B/3B+/3A+/3B/2B/1B+/1A+/Zero 2 W/Zero W/Zero

Marque: Waveshare
Appareils compatibles: Raspberry Pi 4B, 3B+, 3A+, 3B, 2B, 1B+, 1A+, Zero 2W, Zero, Jetson Nano
Technologie de mémoire RAM: DDR3
Processeurs compatibles: ARM Cortex-A57 (Jetson Nano), ARM Cortex-A72 (Raspberry Pi 4), ARM Cortex-A53 (Raspberry Pi 3, 3B+, 3A+, 3B, 2B, 1B+, 1A+), ARM1176JZF-S (Raspberry Pi Zero, Zero W, Zero 2 W)Voir plus
Type de chipset: jetson
Plateforme: Linux
Modèle du CPU: Cortex A9
Interface de la carte graphique: Intégré
Emplacements de mémoire disponibles: 2
Nombre de ports: 3

- This product has been updated to V2 with 800 x 480 resolution (the V1 has a resolution of 640 x 384). The hardware structure and interface of V2 are for the V1, but the software needs to be updated. If you purchase it for the first time, and there is a V2 label on the back of the screen, you can directly use the program for V2.
- This is an E-Ink display HAT for Raspberry Pi, 7.5inch, 800x480 resolution, with embedded controller, communicating via SPI interface. Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on.
- No backlight, keeps displaying last content for a long time even when power down. Ultra low power consumption, basically power is only required for refreshing.
- Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards, Jetson Nano. SPI interface, for connecting with other controller boards like Raspberry/Nucleo, etc. Onboard voltage translator, for 3.3V/5V MCUs.
- Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/STM32).
